Product Description
1. Overview
Model M-100 portable valve grinder is developped for the maintenance of valves as the new generation product. The product can reduce labor intensity, improve labor efficiency and lower maintenance costs.It is widely used in the industries such power generation, petroleum, chemical and metallurgy .It has the following characteristics:
Light, compact, and easy to carry
Split-type assembly makes installation easy and fast
Easy to be used
High efficiency,good grinding quality
Maintenance in the site without valve disassembles and assembles
2. Cone Globe Valve Grinding Machine Technical Parameter
Item |
M-100 | M-100A for Flat Globe Valve | M-100C for Cone Valve |
| Grinding Range（mm） |
DN20-150mm Offline gate valve, globe valve |
Dn20--150mm Flat Globe Valve, Safety Valve, Flat Globe Vavle Seat |
DN20-100mm Cone Globe Valve seat angle: 30°,40°,60°,75°,90° can be Selected |
| Voltage（V） | 220 | 220 | 220 |
| Power（W） | 750 | 750 | 750 |
| Frequency（HZ） | 50 | 50 | 50 |
| Max Grinding Depth（mm） | 250 | 250 | 250 |
| Gross Weight（kg） | 26 | 23.5 | 23.5 |
3. Part list and installation pictures
The said grinder is composed of motors,hand-lift set,driving shafts,Centering Sleeve, lapping head, paper-pressure, gasket, nut and so on.
The following pictures separately expressed installation for various valves.
