6/4D-TAH Slurry Pump
6/4D-TAH Slurry Pump is a single-stage, single-suction and horizontal heavy duty centrifugal slurry pump with a cantilever design, The 6/4 slury pumps are mainly used in solids containing applications.
Product Description
6/4D-TAH Slurry Pump is a single-stage, single-suction and horizontal heavy duty centrifugal slurry pump with a cantilever design, The 6/4 slury pumps are mainly used in solids containing applications. Depending on process conditions, equipment should be suitable for highly abrasive or corrosive liquids.
6/4D-TAH Slurry Pump (High Chrome Alloy Cr27%)
|
Model |
6/4D-TAH |
|
Position of Pump Shaft |
Horizontal pump |
|
Impeller |
Open, semi-open, closed |
|
Color |
Any color |
|
Certificate |
ISO, SGS |
|
HS Code of pump |
8413709990 |
|
Capacity(Flow) |
162~360m³/h |
|
Head |
12-56m |
|
Number of Revolutions |
800-1550RPM |
|
Motor power |
Max 60kw |
TAH Slurry pump 3D structure & seal type
TAH series slurry pumps contain cantilever and horizontal centrifugal pumps, which apply to transport slurry with strong corrosion proof and high concentration for such industries as Metallurgy, mine, coal, power, buliding etc. This kind of pump can be used in multi stages.
TAH slurry pump body consist of replaceable metal or rubber lining and its impeller is made of wear resistant metal or rubber. The shaft seal of TAH series pump may adopt packing seal or centrifugal.
Shaft seal (seal): The shaft seal types of TAH slurry pump include Gland seal, Expeller seal, and mechanical seal.
