Nicer Bearing is a professional electric motor bearing manufacturer and supplier, offering quality options from top manufacturers around the world.
Product Description
Electric motors provide the power necessary to for applications throughout many industries. Electric motor bearings allow these motors to rotate smoothly, quietly, and efficiently, all while addressing key needs like high load capacity, long life spans, and low running noise are all important qualities.
Nicer Bearing is a professional electric motor bearing manufacturer and supplier, offering quality options from top manufacturers around the world. Whether you need a custom part for your specific application or a standard solution to address your performance needs, we can help you find the best, most cost-effective parts for your electric motor needs.
Dimensions: I.D. 40mm, O.D. 90mm, B 23mm, Cr: 31.35KN, Cor: 22.38KN,
Vibration Speed: Low frequency 23.4μm/s, Middle frequency 52.2μm/s, High frequency 1.91μm/s
Vibration Acceleration: 38 db
Dimensions: I.D. 45mm, O.D. 100mm, B 25mm Cr: 40.66KN, Cor: 30KN,
Vibration Speed: Low frequency 15.7μm/s, Middle frequency 39.6μm/s, High frequency 1.72μm/s
Vibration Acceleration: 38 db
Dimensions: I.D. 55mm, O.D. 120mm, B 29mm Cr: 55.05KN, Cor: 41.91KN,
Vibration Speed: Low frequency 17.6μm/s, Middle frequency 41.32μm/s, High frequency 2.74μm/s
Vibration Acceleration: 43 db
Dimensions: I.D. 60mm, O.D. 130mm, B 31mm Cr: 62.88KN, Cor: 48.6KN,
Vibration Speed: Low frequency 42.5μm/s, Middle frequency 98.6μm/s, High frequency 14.05μm/s
Vibration Acceleration: 44 db
Dimensions: I.D. 65mm, O.D. 140mm, B 33mm Cr: 72.21KN, Cor: 56.68KN,
Vibration Speed: Low frequency 55.6μm/s, Middle frequency 109.5μm/s, High frequency 10.6μm/s
Vibration Acceleration: 44 db
Dimensions: I.D. 70mm, O.D. 150mm, B 35mm Cr: 80.1KN, Cor: 63.48KN,
Vibration Speed: Low frequency 89μm/s, Middle frequency 136μm/s, High frequency 12.1μm/s
Vibration Acceleration: 47 db
*We also supply 6200 series and 6300 series electric motor bearing used in motors with 3000 r/m, 6305 and 6400 series used in vibration motor.
