SMT PCB Magazine Unloader
PCB Magazine Loader Unloader with PLC programmable controller and touch screen. Hayawin supports the development, design, development, manufacturing and sales of SMT PCB Magazine Unloader.
Product Description
Product Description
Hayawin is a leading provider of high-quality PCB magazine loader unloader solutions for a wide range of industries. Our state-of-the-art SMT PCB magazine unloader system is designed to provide reliable and efficient magazine line unloading, ensuring optimal productivity and performance.
Our PCB magazine loader unloader system is designed to work seamlessly with your existing production line, allowing for easy integration and enhanced efficiency. Our innovative design ensures that PCBs are unloaded from magazines quickly and efficiently, reducing wait times and increasing throughput.
Our SMT PCB magazine unloader is specifically designed for use in surface-mount technology applications. Its advanced technology ensures that sensitive components are handled with care, reducing the risk of damage and ensuring high-quality output.
Our magazine line unloading system is designed to handle a wide range of magazine sizes and configurations, making it the ideal solution for any production line. Its user-friendly interface and advanced controls allow for easy customization and monitoring, ensuring optimal performance and productivity.
SMT PCB Magazine Unloader Features：
▹ The machine frame adopts high-strength iron plate, aviation aluminum profile, stable and strong
▹ With safety door lock function, equipment shutdown protection
▹ PLC programmable controller + touch screen
▹ Lifting adopts servo motor + precision ball screw, accuracy ±0.1mm
▹Loading and unloading magazine pneumatic clamps ensure more accurate positioning of the magazine
▹ Flow Direction: Left to Right or Right to Left optional
▹ Standard SMEMA interface, can be connected online with other equipment
SMT PCB Magazine Unloader Technical Specification：
|
Cycle time |
≈8S |
|
Magazine Position Number |
2PCS(or customized) |
|
Magazine change time |
≈25S |
|
Power supply |
220V 50HZ |
|
Air supply and usage |
0.4-0.6MPa;≤10L/min |
|
Transport height |
950±30mm |
|
Flow direction |
Left to Right/Right to Left |
|
Step selection |
10-100 (adjustable) |
|
Magazine rack slots |
50PCS |
Model Specification：
|
Model |
YS-ULD250 |
YS-ULD330 |
YS-ULD390 |
YS-ULD460 |
|
Min board size (L*W) |
80×50mm |
80×50mm |
80×50mm |
80×50mm |
|
Max board size (L*W) |
350×250mm |
455×330mm |
530×390mm |
530×460mm |
|
Magazine size (L*W*H) |
355×320×565mm |
460×400×565mm |
535×460×565mm |
535×530×565mm |
|
Dimensions (L*W*H) |
1550×820×1750mm |
1995×1030×1750mm |
2245×1160×1750mm |
2245×1160×1750mm |
Hayawin's SMT PCB magazine unloader is the ideal solution for any production line in need of reliable and efficient magazine line unloading. With its advanced technology, user-friendly interface, and high-quality components and materials, we are confident that our magazine loader unloader system will provide years of trouble-free operation and meet the needs of any industry.
