Globe Valves vs. Gate Valves

Gate valves and globe valves both serve important roles in applications that require control of liquid and media passing through industrial systems. As the most common valves used in industrial plants, they are often used in the same applications and are very similar in appearance, but they have different functionalities.

It is important to understand these differences when deciding what valve type to use in your application. This article discusses the differences between and the purposes of each type of valve.

Globe Valves

At a glance, it is easy to understand why globe valves were named as such. Traditional globe valves closely resemble a globe. Belonging to the linear motion valve family, globe valves are primarily intended to start, stop, and regulate the flow of media. Most globe valves have a top-entry design, meaning you have to access the valve’s internal components from the top.

Globe valves provide a tight, efficient seal to limit the risk of leakage. They are suitable throttling valves because their seats are parallel to the media flow, preventing erosion of the seat when the valve is on. Globe valves experience high-pressure drops and are more resistant to media flow when the valve is turned on.

Applications that encounter high temperatures, high pressures, or highly viscous media call for globe valves. They are appropriate for applications that require a safe, leak-proof solution that resists corrosion. Due to their capabilities, globe valves are more costly than gate valves but are a worthwhile expense in certain applications.

Gate Valves

As part of the shutoff valve family, these linear valves feature a wedge-shaped gate and a rising or non-rising stem to indicate when the valve is open or closed. The primary function of gate valves is to isolate media by providing a tight seal to stop the flow. Unlike globe valves, they don’t regulate the flow of media, but they can accommodate any flow direction.

Gate valves are ideal for applications that require tight sealing. Knife valves, a unique variety of gate valves, are suitable for viscous media. Gate valves are useful in wide variety of above- and below-ground applications and are suitable for all kinds of fluids, including gas and water.
