3V120-06 Directional Control Valve

3V120-06 Directional Control Valve

Product Description

High Flow Rates: Designed to handle high flow rates, ensuring efficient operation in various applications.

Robust Construction: Durable build to withstand challenging industrial environments.

Double or Single Solenoid Operation: Options for either double solenoid for bistable operation or single solenoid for spring return functionality.

Multiple Mounting Options: Can be base mounted, sub-base mounted, or manifold mounted for flexibility in installation.

Manual Override Option: Often includes a manual override for troubleshooting or manual operation in case of power failure.

Parameter

Directional control valves are one of the core elements in a hydraulic circuit. They help directing the fluid to different components in the system. Xingyu provide monoblock, sectional, solenoid operated spool type control valves with different flow capacities and spool options.

Basic of Directional Control Valves

Here are some basic aspects of directional control valves:

Functionality

Directional control valves control the direction of fluid flow in a hydraulic or pneumatic system.

They enable the activation or deactivation of specific actuators, such as cylinders or motors.

Types of Directional Control Valves:

2/2-Way Valve: Has two ports (inlet and outlet) and two positions (open or closed).

3/2-Way Valve: Has three ports (inlet, outlet, and exhaust) and two positions.

4/2-Way Valve: Has four ports and two positions.

4/3-Way Valve: Has four ports and three positions.

5/2-Way Valve: Has five ports and two positions.

5/3-Way Valve: Has five ports and three positions.
