3PC Floating Ball Valve

The 3 Pc Forged Steel Floating Ball Valve is constructed using materials such as ASTM A105, F304, F316, F51, F53, and others. Fabricated through a forging process, these valves consist of three pieces, exhibiting robustness and high-pressure capabilities. Featuring a ball within the body for fluid regulation, the components include body, seat, ball disc, gasket, studs, nuts, cover, o-ring, washer, packing, gland, gland flange, screw, and stem.

These Forged Carbon Steel 3 Piece Design Ball Valves are available in various sizes and dimensions, ranging from ½ inches to 24 inches and DN15 through DN300. Classified as full port valves, they accommodate different pressure capacities.

Features:

1. Construction: The 3PC Floating Ball Valve consists of three separate pieces - a body and two end caps. This design allows for easy maintenance and repair as the valve can be disassembled without removing it from the pipeline.

2. Floating Ball: The ball inside the valve is designed to float in the fluid, allowing it to maintain effective sealing even under high pressure and varying flow conditions.

3. Bi-directional Sealing: The valve is equipped with two seats on opposite sides of the ball, ensuring a tight seal in both directions of flow.

4. Blowout Proof Stem: The stem is designed to prevent it from being blown out of the valve in case of high pressure or other extreme operating conditions.

5. ISO Mounting Pad: The valve has an ISO mounting pad for easy installation of electric or pneumatic actuators, enabling remote or automated operation.

Xiangyu Floating Ball Valve Specifications:

1. Size Range: The 3PC Floating Ball Valve is available in sizes ranging from 1/2" to 24".

2. Pressure Rating: The valve comes in various pressure ratings such as ANSI Class 150 to 2500, ensuring suitability for a wide range of applications.

3. Material Options: The valve is available in different materials such as carbon steel, stainless steel, and alloy steel, allowing for compatibility with various fluids and operating conditions.

4. End Connections: The valve can be provided with different end connections, including threaded, flanged, or butt-welded ends, depending on the requirements of the application.

Applications:

The 3PC Floating Ball Valve is suitable for various applications, including:

1. Oil and Gas: It is widely used in oil refineries, natural gas processing plants, and pipelines for controlling the flow of crude oil, natural gas, and other petroleum products.

2. Petrochemical: The valve is suitable for handling various aggressive chemicals and solvents typically found in petrochemical plants.

3. Power Generation: It is used in power plants for controlling the flow of steam, condensate, and other fluids.

4. Water and Wastewater: The ball valve is employed in water and wastewater treatment plants for regulating the flow of water, sludge, and other fluids.

In conclusion, the 3PC Floating Ball Valve is a versatile and reliable valve that is widely used in various industries. With its robust construction, bi-directional sealing, and easy installation of actuators, it ensures efficient control of fluid flow in a wide range of applications.
