Plastic Medicine Bottle Injection Blow Molding Machine

Product Description

One Step bottle injection blow moulding machine

Plastic bottle molding machine is a full automatic injection blow molding machine, suitable for processing PP, PS, PE, SAN, PMMA, PC, PETG, PEN and other thermoplastic, widely used in pharmaceutical, health care products, food and beverage, cosmetics, etc.

One Mold with Multi-caivity for automatic continuous production technology, using three horizontal station rotary device, hot runner system and multi-stage injection molding system, injection molding, blow molding, demolding three position and action to ensure equipment of high efficiency and energy saving operation, ensure smooth product bottle, the bottleneck of inner and outer diameter and thread high precision, no waste is the standard equipment of modern enterprise environment-friendly production.

	Unit	SZCX 130/30	SZCX 160/45	SZCX 250/60	SZCX 160/50X	SZCX 300/70X	SZCX 700/135X
Dia of screw	mm	40	45	52	45	55	70
Screw L/D		22:1	22:1	23:1	22:1	24:1	24:1
Max injection weight	g	130	160	250	160	300	700
injection clamping force	kn	300	450	673	500	705	1240
opening stroke of mould platen	mm	120	120	140	120	150	160
max platen size of mould	mm	320*270	480*370	700*400	480*370	780*460	1140*520
min mould thickness	mm	180	240	280	240	254	254
dry cycle time	kw	2.8	3	3.2	2.9	2.9	3.2
motor power	kw	23	29.1	29.1*2	29.1	36.7+12	67+12
range of bottle size	kw	2-500	2-750	2-1000	2-750	2-1000	5-1500
compressed air pressure	Mpa	0.7-0.9	0.7-0.9	0.7-0.9	0.7-0.9	0.7-0.9	0.7-0.9
compressed air discharge rate	m3/min	0.3	0.4	0.8	0.6	0.8	1.2
total electrical power	kw	44.534.2	131.1	61.1	44.5	72	119
operation power		30-44%	32-46%	33--46%	34-48%	30-41%	24-32%

Bottle injection molding machine features

Characteristics of FG series machine

1) One step fast molding without scrap, good for continuous production meeting GMP standard;

2) Neck and thread in high precision dimension to meet various sealing requirement;

3) Smooth party lines on body and bottom for perfect surface finishing, various shape available;

4) Max. Uniformity of bottle weight, thickness and volume;

5) High speed production with multi cavities available on different bottle size;

6) Suitable material: PE, PP, PS, SAN, PETG, EVA... etc for various bottles;

7) Different method as option, big space for ease mould changing.

8) Atomated one step injection stretch blow molding machine for medical, cosmetic, food bottle jar use

9) Small plastic bottle injection molding machine for medical, cosmetic, food bottle jar use

Bottle injection molding machine advantages

One step plastic bottle molding machine from Tepai is equipped with professional injection system and precision control system, which can meet the requirements of high-speed opening and closing mold, high clamping force and uniform distribution of clamping force at each position of the mold. The three position rotary lifting system can rotate 120 to make the three positions of injection molding, blow molding and demoulding run continuously and smoothly.

At the same time, due to the use of hydraulic drive linkage mechanism, the positioning of the machine is more accurate, the maintenance cost is lower, and it is more rapid and stable. The demoulding station cooperates with the conveyor belt to realize automatic demoulding, automatic counting and automatic packaging. The whole process avoids manual contact, so that the products produced by the machine can meet the stringent requirements in the field of medicine and health.

As a professional bottle injection molding machine manufacturer, we can assist customers in calculating production costs based on samples, selecting and customizing machinery according to product output, dimensions, weight, and the raw materials used. Upon the machinery's arrival at the factory, we coordinate local engineers to provide on-site installation and training services, as well as equipment maintenance and servicing.
