PG Series Bi-semi-ring Pipe Beveling and Cutting Machine

Introduction of equipment performance

 1.        The PG series double half ring groove cutting machine  developed by Metals Kingdom Industry Limited  company is suitable for cutting and beveling of metal pipes with different materials. For pipes with different materials, processing dimensions or hardness, special tools should be ordered to suit the situation.

2.        The PG series pipe beveling and cutting machine adopts double half ring structure in order to adapt to the working conditions of online pipelines. In the processing of non-assemblable pipelines, the main machine can be split into two halves, closed and fastened accurately on the pipeline before cutting groove. The whole proces only needs one time clamping and completes the work according to different working conditions.

3.        PG series pipe beveling and cutting machine standard configuration is axial dynamic layout. If the axial space is insufficient, the supporting force can be configured.

4.        The series pipe beveling and cutting machine  is equipped with various size clamping and lengthening blocks to meet different diameter pipes.

5.        PG series slope cutters are made of high-quality high-speed steel, suitable for pipes of different materials, and have various angles to choose from.

6.        PG PG series pipe beveling and cutting machine are designed with various power configurations. Users can choose different power modes such as electric, pneumatic and hydraulic according to their needs.

Simple diagram of equipment structure

1.Main body   2. Tool carrier   3.Motor  4 .feed structure

5. Anti transfer safety pin  6. Revolving ring  7 Clamping lengthening block
