Disc Shape Spargers
The product is composed of titanium filter disc, 316L stainless steel housing, 316L stainless steel flange, and sparger gasket. The titanium filter disc is sintered with high-purity titanium powder, and the sparger gasket is a leak-proof gasket specially designed for the spargers by our company.
Product Description
Features
High compressive strength, high temperature resistance and long service life;
Removable for cleaning and reuse;
The pore size is uniform and small, the distribution range is narrow, and the bubbles generated are small;
High porosity, low aeration resistance, high aeration efficiency;
No particles fall off and will not cause secondary pollution to the original liquid.
Titanium disc shape spargers aeration flow diagram (in water test)
Specifications
| No. | Model | Air outlet diameter (mm) | Height (mm) | Connection | AerationArea(㎡) (water depth above 4 meters) |
O2 utilizationRatio |
| 1 | JTBQB-100 | ф100 | 60 | R 1/2'' | 0.4 | 32.22-45.33% |
| 2 | JTBQB-150 | ф150 | 68 | R 1/2'' | 0.8 | 32.22-45.33% |
| 3 | JTBQB-200 | ф200 | 83 | R 1/2'' | 1 | 32.22-45.33% |
