ROCKCHIP RK3566 Cortex-A55 quad-core processor with 22nm chip production process. Equipped with Android/Linux+QT/Ubuntu system, the main frequency is 1.8GHz. Mali-G52 GPU, support H.264 H.265 4K 60Hz video decoding, H.264 H.265 1080P 100Hz encoding
Product Description
Product Description
Model: x3566cv2
Optional configuration: RAM(LPDDR4)+ROM(eMMC) 2+16G and 4+16G
ROCKCHIP RK3566 Cortex-A55 quad-core processor with 22nm chip production process. Equipped with Android/Linux+QT/Ubuntu system, the main frequency is 1.8GHz. Mali-G52 GPU, support H.264 H.265 4K 60Hz video decoding, H.264 H.265 1080P 100Hz encoding, built-in 0.8T computing power NPU, support multi-channel market universal display interface, rich core board interface, all function pins (up to 200pin). Support a number of peripheral expansion, is your best choice in human-computer interaction, industrial control projects.
Tablet computer, learning machine, face recognition, gate channel, face payment, industrial robot, medical detection equipment, license plate recognition, advertising machine, digital signage, intelligent autonomous terminal, intelligent retail terminal and other related products.
The SOM for interactive self-service terminal is a compact and highly integrated module that combines the essential components of a self-service terminal into a single board. It consists of a powerful processor, memory, storage, and various interfaces, all packed into a small form factor. This module serves as the core engine of interactive self-service terminals, enabling seamless and efficient operation.
CPU |
RK3566 |
Main Frequency |
Quad-core A55(1.8GHz) |
Memory / Storage |
DDR: 2GB standard, 4GB hardware compatible |
Power ICs |
Uses RK817, supports adapter, battery power |
Operating System |
android, linux, debain, ubuntu |
LCD Interface |
Support DSI/LVDS/EDP/HDMI interface output |
Touch Interface |
Capacitive touch, extendable with resistive touch using USB or serial port |
Audio Interface |
IIS/PCM/TDM Interface |
SPDIF Interface |
1 x 8-channel optical audio output interface |
SD card interface |
2 SDIO output channels |
emmc Interface |
On-board emmc interface, no additional pinout |
Ethernet Interface |
Supports 1 Gigabit Ethernet |
USB HOST2.0 interface |
2-way HOST2.0 |
USB HOST3.0 interface |
1 way HOST3.0 |
OTG Interface |
1 OTG interface |
UART Interface |
10-way serial port, support with flow control serial port |
PWM Interface |
16 PWM outputs |
IIC Interface |
6 IIC outputs |
SPI Interface |
4 SPI outputs |
ADC Interface |
2 ADC outputs (6 unpinned) |
CAN Interface |
Not supported |
Camera Interface |
4-way CSI input |
HDMI Interface |
1 HDMI2.1 TX |
PCIE Interface |
1 x PCIe2.1 |
SATA Interface |
2 way |
